5-811X UDS Spicer – 5-811X Universal Joint
$24.75
11 in stock
14 People watching this product now!
Description
5-811X — 7290 series, 1.125″ cap, 2.625″ width. Proven sealed universal joint. Verify cap dia and snap ring style before ordering.
Full Description
The 5-811x is a 7290 series inside snap ring retention universal joint measuring 1.125" cap dia | 2.625" width. The 5-811x is sealed, no grease fitting required. Every 5-811x is verified for cap diameter, bearing width, and snap ring groove dimensions before it ships from Universal Driveshafts.
5-811X -- 7290 Series Cap & Width Specifications
The 5-811x specs: 1.125" cap dia | 2.625" width. Cap diameter determines which yoke bore it fits -- the cap must seat fully into the yoke without play. Bearing width (2.625" across the body) controls the span between yoke ears. A cross that is too wide won't fit; too narrow and the snap rings don't seat in the groove. SELAED - DETROIT.
Verify the yoke bore diameter against the 5-811x cap size before installing. The snap ring style (inside snap ring retention) must match the yoke groove pattern -- OSR yokes have an external groove; ISR yokes have an internal groove. The 5-811x is factory-sealed -- no maintenance interval, no grease fitting. Correct installation torque on the strap kit or U-bolt is critical -- undertorqued straps allow the cap to walk under load.
Installation Notes for 5-811x
Before installing the 5-811x, clean the yoke bores of any rust, burrs, or old bearing material. The bearing cups must drop in by hand -- never drive them in with a hammer directly on the cup. Use a proper cross-and-bearing installation tool or a press. Driving a cup in at an angle cocks the needle bearings and destroys the 5-811x before it ever sees load.
After installation, verify full rotation without binding. A binding cross indicates a cup is cocked or seated too deep. The 5-811x should articulate freely through the full operating angle of your driveshaft before the vehicle is lowered off the lift.
Key Features
- Series: 7290 series
- Cap dia: 1.125" -- must match yoke bore exactly
- Width: 2.625" -- controls yoke ear span
- Style: inside snap ring retention -- verify yoke groove type before ordering
- Sealed -- factory pre-lubed, no maintenance required
- Brand: SPICER
- Note: SELAED - DETROIT
Specifications
- SKU: 5-811X
- Part Number: 5-811X
- Brand: SPICER
- Series: 7290
- Cap Dia 1: 1.125"
- Width 1: 2.625"
- Snap Ring Style: ISR
- Lube: No -- sealed
- Notes: SELAED - DETROIT
Additional information
| Brand | SPICER |
|---|---|
| Cap dia 1 | 1.125 |
| Lube | N |
| Notes | SELAED – DETROIT |
| Partn number | 5-811X |
| Series | 7290 |
| Style | ISR |
| Width 1 | 2.625 |
