3-2-1789 Flange Yoke 1410 series, 4x.509 Holes on 4.750 BC, 3.750M pilot
$36.52
2 in stock
14 People watching this product now!
Description
The 3-2-1789 Flange Yoke from the 1410 Series is designed for robust performance in heavy-duty applications. It features a male pilot diameter of 3.750 inches and an outside snap ring. With a swing diameter of 5.750 inches and a bolt circle diameter of 4.750 inches, it provides reliable connectivity. The yoke includes 4 drilled bolt holes, each with a diameter of 0.509 inches.
Additional information
| Bolt circle dia | 4.750 |
|---|---|
| Bolt hole dia | 0.509 |
| Cj to flat | 2.000 |
| Partn number | 3-2-1789 |
| Pilot dia | 3.750 ,M |
| Series | 1410 |
| Bolt Holes | 4 |
| Swing dia | 5.750 |
