2580-50 – Center Support Bearing – Audi Application – 1.181″ ID – 1.500″ Center Bearing To Base
$119.86
10 in stock
Description
2580-50 center support bearing, Audi AWD, 1.181″ bore, 1.500″ center-to-base height, 7.375″ center-to-center mount holes.
Full Description
The 2580-50 is one of the lower-profile Audi 2580 center support bearings at 1.500" center-to-base. Lower-profile carriers are found on Audi platforms where the propshaft runs close to the tunnel floor -- the low carrier height keeps the rear shaft section from running at a steep upward angle toward the rear differential.
- Part: 2580-50 | Application: Audi quattro/AWD
- Bore: 1.181" | Center-to-base: 1.500"
- Mount hole span: 7.375" C-to-C
- Sealed bearing with bonded rubber isolator, no repack interval
Tip: When reinstalling, tighten bracket fasteners to Audi-specified torque. Under-torquing allows the carrier to vibrate against the crossmember, eroding the mounting holes and eventually causing the bracket to crack at the weld point -- a failure that damages the driveshaft, not just the carrier.
Additional information
| Application | Audi |
|---|---|
| Bearing id | 1.181 |
| Center bearing to base | 1.500 |
| Ctr to ctr of mount holes | 7.375 |
| Notes | Double check centerline to centerline and bearing height. |
| Partn number | 2580-50 |
