212032-1X Center Support Bearing GMC Sierra / Chevy Silverado 12472424 With 0.380 Spacer Stud In Bracket
$25.38
+50 in stock
15 People watching this product now!
Description
212032-1X Center Support Bearing — Chevy Gmc series, 1.574″ inner dia | 2.625″ center-to-base | 6.625″ mount spacing. Premium replacement. Verify inner dia and mount spacing.
Full Description
The 212032-1X center support bearing supports the midshaft section of a two-piece driveshaft, keeping it running concentric with the vehicle's drivetrain axis. When this bearing fails, the midshaft droops and the driveshaft angles change — you'll feel it as a vibration that gets progressively worse at highway speed. The 212032-1X center support bearing is the correct replacement for Chevy Gmc series applications, with the exact inner diameter and mount hole spacing your application requires.
212032-1X Center Support Bearing — Chevy Gmc Series Dimensions & Mount Specs
The 212032-1X center support bearing specs: 1.574" inner dia | 2.625" center-to-base | 6.625" mount spacing. Has a 0.380" spacer / Rubber w/ canister / Studs in bracket M10-1.5. Application: Chevy Gmc series. Inner diameter must match the midshaft stub OD exactly — a loose fit allows the bearing to walk on the shaft, which causes vibration and accelerates wear on both the bearing race and the shaft surface. Mount hole center-to-center spacing must match your crossmember bracket.
When replacing a center support bearing on a two-piece shaft, replace the complete assembly — bearing race, rubber isolator, and bracket together. A new race in an old hardened rubber mount still vibrates. The rubber isolator is what actually absorbs the midshaft movement; without it the bearing transmits every frequency directly to the frame.
Key Features
- Application: Chevy Gmc series — verify your driveshaft series matches
- Bearing inner dia: 1.574" — must match midshaft stub OD exactly
- Center-to-base: 2.625" — height from shaft centerline to mounting surface
- Mount hole spacing: 6.625" — must match crossmember bracket exactly
- Complete assembly — bearing race, rubber isolator, and bracket as one unit
- Rubber isolator included — absorbs midshaft vibration, reduces NVH to frame
- Note: Has a 0.380" spacer / Rubber w/ canister / Studs in bracket M10-1.5
Specifications
- SKU: 212032-1X
- Brand: UDS
- Application: Chevy Gmc Series
- Bearing ID: 1.574"
- Center to Base: 2.625"
- Mount Hole Spacing: 6.625"
- Notes: Has a 0.380" spacer / Rubber w/ canister / Studs in bracket M10-1.5
Additional information
| Application | Chevy Gmc |
|---|---|
| Bearing id | 1.574 |
| Center bearing to base | 2.625 |
| Ctr to ctr of mount holes | 6.625 |
| Notes | Has a 0.380" spacer / Rubber w/ canister / Studs in bracket M10-1.5 |
| Partn number | 212032-1X |
