1480-15LR Carrier Bearing Land Rover Freelander CBLR 1996-2006 Center Support Bearing MK1 OE: TOQ000040, TOQ000010
$25.12
39 in stock
19 People watching this product now!
Description
1480-15LR center bearing — Land Rover Freelander MK1 all models 1996-2006 (except V6). OE: TOQ000040/TOQ000010. Bearing ID: 1.181″. Spacing: 5.400″.
Full Description
The 1480-15LR is the correct center support bearing for the Land Rover Freelander MK1, covering all engine variants from 1996 to 2006 with the exception of the V6. The OE cross-references are TOQ000040 and TOQ000010. The 1480 designation in the part number refers to the mounting bracket and rubber isolator geometry, not a U-joint series.
The Freelander MK1 uses a two-piece rear driveshaft arrangement on all-wheel-drive variants. The center bearing sits at the driveshaft midpoint, carried in a rubber-isolated bracket bolted to the underside of the transmission tunnel. Rubber isolator condition should be assessed along with bearing condition - deteriorated rubber will cause vibration even with a new bearing installed.
- Part Number: 1480-15LR
- OE Cross: TOQ000040 / TOQ000010
- Application: Land Rover Freelander MK1 1996-2006 (excl. V6)
- Bearing ID: 1.181"
- Center-to-Base: 2.375"
- Mount Hole Spacing: 5.400"
The 5.400" center-to-center mount hole spacing and 2.375" height from bearing CL to bracket base are both OEM-matched dimensions. Deviation from either value would result in incorrect driveshaft angle and associated vibration. Verify year and engine code before ordering as Freelander variants outside this range may use different configurations.
View all center support bearings.
Additional information
| Application | Landrover |
|---|---|
| Bearing id | 1.181 |
| Center bearing to base | 2.375 |
| Ctr to ctr of mount holes | 5.400 |
| Notes | Fits the Land Rover Freelander MK1 all models 96-06 (Except V6) |
| Partn number | 1480-15LR |
