3-2-1329 Flange Yoke 1410 Series, Pilot: 2.750 , Bolt Circle Diameter: 3.750 , Multiple applications
$27.97
24 in stock
19 People watching this product now!
Description
3-2-1329 Flange Yoke — 1410 series, 3.750 bolt circle | 2.750 pilot | 4×0.500 bolt holes | 1.688″ CJ-to-flat. Genuine bolt-on replacement. Verify bolt circle and pilot before ordering.
Full Description
The 3-2-1329 flange yoke is the direct bolt-on connection between your 1410 series driveshaft and the differential or axle housing flange. Bolt circle and pilot diameter are the two specs that determine whether this part fits — everything else is secondary. The 3-2-1329 flange yoke is machined to one specific set of dimensions, and those dimensions have to match your axle flange exactly.
3-2-1329 Flange Yoke — 1410 Series Specifications & Fitment
The 1410 series covers HD trucks — F-250/350/450, Ram 2500/3500, Dana 60/70 axles. The 3-2-1329 flange yoke specs: 3.750 bolt circle | 2.750 pilot | 4x0.500 bolt holes | 1.688" CJ-to-flat. Rec Bolt Pattern. Pilot diameter is what centers the yoke on the companion flange — that dimension must match exactly or the driveshaft will run off-center at speed. Bolt circle determines your hole pattern match.
Before ordering the 3-2-1329 flange yoke, measure your diff flange bolt circle and pilot diameter directly. Don't rely on series designation alone — after an axle swap, the flange dimensions may differ from the original factory spec. Brand: UDS. Verify, then order.
Key Features
- Series: 1410 — built for HD trucks — F-250/350/450, Ram 2500/3500, Dana 60/70 axles
- Bolt circle: 3.750 — must match axle/diff flange hole pattern exactly
- Pilot dia: 2.750 — centers yoke on companion flange, no play allowed
- 4 bolt holes at 0.500 — verify hole count and size
- CJ-to-flat: 1.688" — affects driveshaft working angle clearance
- Brand: UDS — direct-fit replacement
- Note: Rec Bolt Pattern
Specifications
- SKU: 3-2-1329
- Brand: UDS
- Series: 1410
- Bolt Circle: 3.750
- Pilot Dia: 2.750
- Bolt Holes: 4
- Bolt Hole Dia: 0.500
- CJ to Flat: 1.688"
- Notes: Rec Bolt Pattern
Additional information
| Series | 1410 |
|---|---|
| Pilot dia | 2.750 |
| Bolt circle dia | 3.750 |
| Bolt hole dia | 0.500 |
| Bolt Holes | 4 |
| Pilot type | M |
| Notes | Rec Bolt Pattern |
| Cj to flat | 1.688 |
