Brand:
2687452732500 Flange Yoke 68745 , 52×147 Serrated 155mm , CL To End: 100mm
$164.46
10 in stock
11 People watching this product now!
Description
2687452732500 Flange Yoke — 68745 series, 155.50 bolt circle | XS 155 pilot | 100MM” CJ-to-flat. Complete bolt-on replacement. Verify bolt circle and pilot before ordering.
Full Description
Replacing a worn or damaged flange yoke starts with getting the right part. The 2687452732500 flange yoke is dimensioned for one bolt circle, one pilot diameter, and one drivetrain series — 68745 series. A mismatched bolt circle means the yoke won't seat flat. A wrong pilot means the driveshaft runs off-center. The 2687452732500 flange yoke removes both risks.
2687452732500 Flange Yoke — 68745 Series Specifications & Fitment
The 2687452732500 flange yoke specs: 155.50 bolt circle | XS 155 pilot | 100MM" CJ-to-flat. FLANGE YOKE 52X147.2 - 155 OD- 68745. Pilot diameter is what centers the yoke on the companion flange — that dimension must match exactly or the driveshaft will run off-center at speed. Bolt circle determines your hole pattern match.
Before ordering the 2687452732500 flange yoke, measure your diff flange bolt circle and pilot diameter directly. Don't rely on series designation alone — after an axle swap, the flange dimensions may differ from the original factory spec. Brand: UDS. Verify, then order.
Key Features
- Series: 68745 — built for this drivetrain application
- Bolt circle: 155.50 — must match axle/diff flange hole pattern exactly
- Pilot dia: XS 155 — centers yoke on companion flange, no play allowed
- CJ-to-flat: 100MM" — affects driveshaft working angle clearance
- Brand: UDS — direct-fit replacement
- Note: FLANGE YOKE 52X147.2 - 155 OD- 68745
Specifications
- SKU: 2687452732500
- Brand: UDS
- Series: 68745
- Bolt Circle: 155.50
- Pilot Dia: XS 155
- Bolt Hole Dia: 13
- CJ to Flat: 100MM"
- Notes: FLANGE YOKE 52X147.2 - 155 OD- 68745
Additional information
| Bolt circle dia | 155.50 |
|---|---|
| Bolt hole dia | 13 |
| Brand | UDS |
| Notes | FLANGE YOKE 52X147.2 – 155 OD- 68745 |
| Partn number | 2687452732500 |
| Pilot dia | XS 155 |
| Series | 68745 |
| Cj to flat | 100MM |
