1280-15 – Center Support Bearing – Nissan Juke 11-17 – 1.181 – 570 – 7.125
$81.33
Out of stock
16 People watching this product now!
Description
1280-15 center support bearing, Nissan Juke 11-17 series. 1.181″ inner dia | 570″ center-to-base | 7.125″ mount hole spacing. Verify inner diameter and mount hole spacing before ordering.
Full Description
Driveshaft vibration on 2-piece shafts almost always traces back to the center support bearing. The 1280-15 is the replacement -- correct inner diameter, correct bracket dimensions.
1280-15 Center Support Bearing -- Nissan Juke 11-17 Series Dimensions
Specs on the 1280-15 center support bearing: 1.181" inner dia | 570" center-to-base | 7.125" mount hole spacing. Bolt heads opposite side of spacers. Built for Nissan Juke 11-17 series applications. The inner diameter must match your midshaft stub -- too loose and the bearing walks; too tight and it won't press on.
Mount hole center-to-center spacing is the most overlooked spec on CSBs. If the holes don't match your crossmember bracket, the bearing will be offset and the shaft will run off-center.
Key Features
- Application: Nissan Juke 11-17 series -- verify your driveshaft series matches
- Bearing inner dia: 1.181" -- must match midshaft stub OD exactly
- Center-to-base: 570" -- height from shaft centerline to mounting surface
- Mount hole spacing: 7.125" -- must match crossmember bracket hole pattern
- Rubber isolator included -- absorbs vibration, reduces NVH at the midshaft
- Complete assembly -- bearing race, rubber mount, and bracket in one unit
- Note: Bolt heads opposite side of spacers
Specifications
- SKU: 1280-15
- Brand: UDS
- Application: Nissan Juke 11-17 Series
- Bearing ID: 1.181"
- Center to Base: 570"
- Mount Hole Spacing: 7.125"
- Notes: Bolt heads opposite side of spacers
Additional information
| Application | Nissan Juke 11-17 |
|---|---|
| Bearing id | 1.181 |
| Center bearing to base | 570 |
| Ctr to ctr of mount holes | 7.125 |
| Notes | Bolt heads opposite side of spacers |
| Partn number | 1280-15 |
