5-2-279 Flange Yoke 1610 series, 8 x .375 Holes on 6.125 BCD, 6.625 MALE pilot
$74.82
32 in stock
13
People watching this product now!
Description
5-2-279 Flange Yoke — 1610 series, 6.125 bolt circle | 6.625 pilot | 8×0.375 bolt holes | 3.000″ CJ-to-flat. Professional bolt-on replacement. Verify bolt circle and pilot before ordering.
Full Description
The 5-2-279 flange yoke is the direct bolt-on connection between your 1610 series driveshaft and the differential or axle housing flange. Bolt circle and pilot diameter are the two specs that determine whether this part fits — everything else is secondary. The 5-2-279 flange yoke is machined to one specific set of dimensions, and those dimensions have to match your axle flange exactly.
5-2-279 Flange Yoke — 1610 Series Specifications & Fitment
The 1610 series covers Class 5-7 commercial and heavy fleet. The 5-2-279 flange yoke specs: 6.125 bolt circle | 6.625 pilot | 8x0.375 bolt holes | 3.000" CJ-to-flat. Pilot diameter is what centers the yoke on the companion flange — that dimension must match exactly or the driveshaft will run off-center at speed. Bolt circle determines your hole pattern match.
Before ordering the 5-2-279 flange yoke, measure your diff flange bolt circle and pilot diameter directly. Don't rely on series designation alone — after an axle swap, the flange dimensions may differ from the original factory spec. Brand: UDS. Verify, then order.
Key Features
- Series: 1610 — built for Class 5-7 commercial and heavy fleet
- Bolt circle: 6.125 — must match axle/diff flange hole pattern exactly
- Pilot dia: 6.625 — centers yoke on companion flange, no play allowed
- 8 bolt holes at 0.375 — verify hole count and size
- CJ-to-flat: 3.000" — affects driveshaft working angle clearance
- Brand: UDS — direct-fit replacement
Specifications
- SKU: 5-2-279
- Brand: UDS
- Series: 1610
- Bolt Circle: 6.125
- Pilot Dia: 6.625
- Bolt Holes: 8
- Bolt Hole Dia: 0.375
- CJ to Flat: 3.000"
Additional information
| Bolt circle dia |
6.125 |
|---|---|
| Bolt hole dia |
0.375 |
| Cj to flat |
3.000 |
| Partn number |
5-2-0279 |
| Pilot dia |
6.625 ,M |
| Series |
1610 |
| Bolt Holes |
8 |
