2852-1082 – CV Joint Kit – 38 x 1.14″ Splines – Inner Race Width 26.2mm – Outer Race Width 32″
$175.28
30 in stock
13 People watching this product now!
Description
CV Joint Kit for Chrysler applications, featuring 38 splines and an inner race width of 26.2mm.
Full Description
The 2852-1082 CV Joint Kit is engineered specifically for Chrysler applications, making it an essential component for maintaining optimal driveline performance. This Rzeppa-style joint allows for constant velocity power transfer at varying angles, ensuring smooth operation during turns and acceleration. With 38 splines and a 1.14" spline diameter, this joint is designed to handle the torque demands typical in Chrysler vehicles. Installation of the 2852-1082 requires attention to detail. Use the specified (6) M10-1.5x55mm bolts for secure mounting, and ensure the outer snap ring is properly engaged to prevent dislodgement during operation. The inner race width of 26.2mm and outer race width of 32mm provide a robust interface that can withstand the stresses of daily driving. Common failure symptoms include clicking noises during turns, which indicate potential wear or damage to the joint. Regular inspection of the boot for tears and grease contamination is crucial to prolonging the life of the CV joint. When replacing, always pack the joint with the recommended grease and use new boots and clamps for a complete and reliable installation.
- 38 splines for high torque capacity
- 1.14" spline diameter for precise fit
- Inner race width of 26.2mm for durability
- Ensure proper clip engagement during installation
- Monitor for clicking noises as a wear indicator
Additional information
| Style | Rzeppa |
|---|---|
| Bolt hole count | 6 |
| Bolt hole dia | 10.2mm |
| Inner race width | 26.2mm |
| Outer dia | 108mm |
| Outer race width | 32 |
| Splines count | 38 |
| Splines dia | 1.14 |
| Application | CHRYSLER |
| Bolt circle dia | 94mm |
| Notes | (6) M10-1.5x55mm. Outside snap ring version, mates with 2852-1082 ,Chrysler |
| Partn number | 2852-1082 |
| Boot cap part | INCLUDED |
