Brand:
2687402700550 Flange Yoke 68740 – 2040 Series , 47,6×1345 Serrated 155
$152.78
8 in stock
17 People watching this product now!
Description
687.40 series 2687402700550 flange yoke. 130 bolt circle | XS 155 pilot | 13 bolt holes | 3.375″ CJ-to-flat. Match bolt pattern and pilot to your axle flange.
Full Description
The 2687402700550 flange yoke bolts directly to your differential or axle housing flange -- the fixed connection point between the axle output and the driveshaft end. Bolt circle and pilot diameter have to be exact.
2687402700550 Flange Yoke -- 687.40 Series Dimensions & Fit
The 2687402700550 flange yoke specs: 130 bolt circle | XS 155 pilot | 13 bolt holes | 3.375" CJ-to-flat. Note: FLAGE YOKE 47.6X135 - 2040 SERIES - 68740. Measure your axle flange bolt circle and pilot before ordering.
Flange yoke tolerances leave no room for approximation. If the bolt circle is off by even a fraction, the yoke won't seat flat -- and a poorly seated flange yoke will crack the companion flange over time.
Key Features
- Series: 687.40 -- built for this drivetrain application
- Bolt circle: 130 -- must match diff/axle flange exactly
- Pilot diameter: XS 155 -- centers yoke on companion flange
- CJ-to-flat: 3.375" -- affects working angle and clearance
- Note: FLAGE YOKE 47.6X135 - 2040 SERIES - 68740
Specifications
- SKU: 2687402700550
- Brand: UDS
- Series: 687.40
- Bolt Circle: 130
- Pilot Dia: XS 155
- Bolt Hole Dia: 13
- CJ to Flat: 3.375"
- Notes: FLAGE YOKE 47.6X135 - 2040 SERIES - 68740
Additional information
| Bolt circle dia | 130 |
|---|---|
| Bolt hole dia | 13 |
| Brand | UDS |
| Notes | FLAGE YOKE 47.6X135 – 2040 SERIES – 68740 |
| Partn number | 2687402700550 |
| Pilot dia | XS 155 |
| Series | 687.40 |
| Cj to flat | 3.375 |
