211489X – Cv Flange Yokes – 1210 Series – Ball Stud Dia 0.5″ – Bolt Circle Dia 3.5

The 211489X Cv Flange Yoke is engineered for reliability and precision in your driveline setup. This specific yoke belongs to the 1210 Series, which is known for its robust construction and compatibility with various applications. With a ball stud diameter of 0.5″ and a bolt circle diameter of 3.5″, it ensures a secure connection to your driveshaft components.

When selecting a yoke, it’s crucial to match the series and dimensions accurately. The 1210 Series yoke differs from others like the 1310 or 1350 Series, primarily in its bolt hole and stud dimensions. Using a yoke that doesn’t match these specifications can lead to improper fitment and potential driveline failure. For instance, a 1350 Series yoke may appear similar but will not accommodate the same U-joint due to its larger cap diameter.

• Ball Stud Diameter: 0.5″
• Bolt Circle Diameter: 3.5″
• Bolt Hole Diameter: 484″
• Pilot Diameter: 2″
• C L To Face: 1.625″

Installation requires careful attention to spline engagement depth and phasing with the opposite yoke. Never force spline entry, as this can damage the yoke or the mating components. The 211489X is a reliable choice for those looking to maintain or upgrade their driveline systems with a focus on compatibility and durability.
