Sale!

2-2-489 | Flange Yoke 1330 Series , Holes: 4 x 0.438 | Bolt Circle Dia : 3.750 , Pilot: 2.750M - Image 1

Click to enlarge

Brand:

2-2-489 | Flange Yoke 1330 Series , Holes: 4 x 0.438 | Bolt Circle Dia : 3.750 , Pilot: 2.750M

SKU: 2-2-489

$20.73

24 in stock

19 People watching this product now!

Description

Flange Yoke
1330 series, Holes: 4 x 0.438 | Bolt Circle Dia : 3.750 , Pilot: 2.750M

Additional information

Bolt circle dia	3.750
Bolt hole dia	0.438
Cj to flat	1.562
Partn number	2-2-489
Pilot dia	2.750 , M
Series	1330
Bolt Holes	4
Brand	UDS
Notes	REQUIRES A 1330 SERIES UNIVERSAL JOINT

More from the same Category

Pasted 119 1 1 1

3102-36

$93.82

Bolt circle dia	2.875
Bolt hole dia	0.380
Cj to flat	1.375
Partn number	2-2-349 , 3102-36U , N2-2-349
Pilot dia	3.625 , OD
Series	1310
Bolt Holes	4

Pasted 129 1 1 1

3102-236X

$92.53

Bolt circle dia	3.150
Bolt hole dia	0.331
Cj to flat	2.671
Partn number	3102-236X
Pilot dia	2.362 , M
Series	1310
Bolt Holes	6

3102-250

$88.07

Bolt circle dia	3.850
Bolt hole dia	0.320
Cj to flat	2.670
Partn number	3102-250
Pilot dia	2.250 , M
Series	1310
Bolt Holes	6

3102-191

$45.85

Bolt circle dia	3.200
Bolt hole dia	0.325
Cj to flat	1.750
Partn number	3102-191
Pilot dia	1.968 , M
Series	1310
Bolt Holes	4

71eGha6PS0L. AC SL1500 1

10-2-29

$102.47

Partn number	10-2-29
Series	1000
Pilot dia	2.250
Bolt circle dia	2.750
Bolt hole dia	4
Brand	SPICER
Notes	Rec Bolt Pattern
Remaining stock	50+
Bolt Holes	4

3102-21

$43.87

Bolt circle dia	3.200
Bolt hole dia	0.395
Cj to flat	1.781
Partn number	3102-21
Pilot dia	1.968 , M
Series	1310
Bolt Holes	4

3102-263 Flange Yoke 1310 DODGE FRONT FLANGE, sq pattern

$69.29

Bolt circle dia	4.330
Bolt hole dia	0.475
Cj to flat	2.060
Partn number	3102-263
Pilot dia	2.630 , F
Series	1310
Bolt Holes	4

3102-271

$57.39

Bolt circle dia	3.307
Bolt hole dia	0.412
Cj to flat	1.750
Partn number	3102-271
Pilot dia	1.850 , M
Series	1310
Bolt Holes	4

3102-192

$41.86

Bolt circle dia	2.980
Bolt hole dia	0.325
Cj to flat	1.750
Partn number	3102-192
Pilot dia	1.968 , M
Series	1310
Bolt Holes	4

3102-253

$46.62

Bolt circle dia	3.118
Bolt hole dia	0.338
Cj to flat	1.712
Partn number	3102-253
Pilot dia	2.250 , M
Series	1310
Bolt Holes	4

3102-362

$52.97

Bolt circle dia	4.133
Bolt hole dia	0.410
Cj to flat	1.685
Partn number	3102-362
Pilot dia	2.362 , M
Series	1310
Bolt Holes	4

3102-216

$69.49

Bolt circle dia	4.520
Bolt hole dia	0.489
Cj to flat	2.000
Partn number	3102-216
Pilot dia	2.162 , F
Series	1310
Bolt Holes	4

6fd1 2 2 899 1 DSP 0 1 228x228 1

3102-39 | 2-2-899-1 , 1310 Series Nissan / Subaru Pilot: 57mm male , 2.250 Inch

$22.14

Bolt circle dia	2.750
Bolt hole dia	0.315
Cj to flat	1.625
Partn number	3102-39
Pilot dia	2.245 , M
Series	1310
Bolt Holes	4
Brand	UDS
Notes	Mostly used on Nissan

3102-221X

$91.77

Bolt circle dia	3.150
Bolt hole dia	0.405
Cj to flat	2.671
Partn number	3102-221X
Pilot dia	2.204 , M
Series	1310
Bolt Holes	6
