T3R-3-9161HP – Transmission Yokes – 3R Series – 31/32 X 1.391 Splines – 1.886″ Hub Dia
$237.28
Description
T3R-3-9161HP is your go-to Transmission Yoke for Short TH400 applications. This yoke connects seamlessly to GM transmissions, ensuring a reliable fit for those working with 31/32 X 1.391 splines. Before installation, double-check your spline count and ensure it matches the output shaft. A common oversight is mismatching spline counts, which can lead to installation headaches.
Crafted from forged steel, the T3R-3-9161HP delivers durability and strength, making it suitable for high-performance applications. The 1.886″ hub diameter is designed to fit snugly, so make sure to verify the hub diameter against your existing components. This yoke is compatible with a range of GM transmissions, including the 6L50, 6L80E, and various transfer cases like NP241C and NP263.
- Check spline engagement depth before sliding the yoke on.
- Ensure proper phasing with the opposite yoke to avoid vibration issues.
- Inspect the mating surfaces for any signs of wear or damage.
- Torque fasteners to the manufacturer’s specifications for a secure fit.
With a center U joint to end measurement of 7.500″, this yoke is engineered for optimal performance. Remember, proper installation is key to maximizing the lifespan of your driveline components. Trust the T3R-3-9161HP for your next project, and experience the difference in quality and fit.
| Center u joint to end | 7.500 |
|---|---|
| Counter bore dia | 0 |
| Hub dia | 1.886 |
| Notes | Short TH400 / Forged Steel / CHROMOLY |
| Partn number | T3R-3-9161HP |
| Remaining stock | <10 |
| Series | 3R |
| Splines count dia | 31/32 X 1.391 |
