2687602300510 Flange Yoke XS 180 Serrated 59×167.8 Bolt Circle Diameter 5.905inch FY2060-180
$157.58
21 in stock
Description
The 2687602300510 Flange Yoke is engineered for demanding driveline applications, particularly in environments where durability and precision are paramount. This yoke, identified as the 59×167.8 XS180, boasts a bolt circle diameter of 150M | 5.905″ and a bolt hole diameter of 15 mm, making it an excellent choice for various setups. The pilot diameter of XS 180 mm ensures compatibility with a range of components, allowing for seamless integration into your driveline system.
In many applications, especially in high-performance vehicles, the flange yoke plays a crucial role in connecting the driveshaft to the transmission or differential. The 68760 Series designation indicates this yoke’s robust construction, designed to withstand the rigors of heavy loads and high torque. Proper installation is key; ensure that the spline engagement depth is correct and that the yoke is phased correctly with its counterpart. Never force the spline entry, as this can lead to premature wear or failure.
- Bolt Circle Diameter: 150M | 5.905″
- Bolt Hole Diameter: 15 mm
- Pilot Diameter: XS 180 mm
- Number of Bolt Holes: 4
- Series: 68760
Whether you’re working on a fleet vehicle or a performance build, the 2687602300510 Flange Yoke is a reliable choice that delivers the strength and precision you need for optimal driveline performance.
| Bolt circle dia | 150M | 5.905" |
|---|---|
| Bolt hole dia | 15 |
| Brand | UDS |
| Notes | Flnage Yoke 59×167.8 XS180 |
| Partn number | FY2060-180 |
| Pilot dia | XS 180 |
| Series | 68760 |
| Bolt Holes | 4 |
