Conversion Driveshaft – Flange to U-Joint – Aluminum, 4″ OD, Ford F250/F350, 4WD, Super Duty Truck

SKU: 4A1410-SLIP_Ford_FL-UJ

$1,209.07

  • Required Driveshaft Measurements:

    We invite you to proceed with your order today, and anticipate sending a follow-up communication to gather essential details. Alternatively, you may expedite the process by providing your measurements below. Please measure from the transfer case seal to the flat face of the differential, where the driveshaft's 4-bolt flange is mounted. Your driveshaft order remains pending until we receive this vital information.

    *Driveshaft Length

    Write your driveshaft length here.

Add to wishlist
Compare
11 People watching this product now!

Fast Shipping

Choose your Delivery Company

2k products

And múltiple Payment methods

24/7 Support

Unlimited help via our support channels

2-3 day Delivery

Track all your orders

Description

Weld Yoke Material:
Aluminum 6061-T6 Forged Yoke
Tube Material: 0.125 Inch WALL 6061-T6 Seamless
Tube Outside Diameter: 4 Inch OD
U-Joint: Spicer 5-1410XU
1410 Series
U-Joint Size: 1 3/16 Inch Cap x 4.188 Inch Span
Premium Non-Greasable
Custom Length Options:
Max length 75.00 inches flat to center of u-joint.
Transfer Case Flange Yoke:
N3-2-1709
Differential U-joint:
U-Joint: 1410 Series
1 3/16 Inch Cap x 4.188 Inch Span
Additional information
Weight 28 lbs
Dimensions 7.5 × 7.5 × 83 in
Vehicle

Ford
Tube diameter

4" OD
d-year

2000 – 2018
Length

Custom
Max length

75.00"
Material

ALUMINUM
Series

1410
Model

F250/F350 SD
