9533-4724 Unwelded 1310 series
$101.68
+50 in stock
20 People watching this product now!
Description
The 9533-4724 is a 1310 Series unwelded driveshaft assembly ideal for custom applications.
Full Description
When you’re working on a custom driveline project, the 9533-4724 driveshaft is a critical component. This unwelded assembly in the 1310 Series allows for precise sizing and welding, making it perfect for DIY applications. With a minimum to maximum length of approximately 55 7/16" to 57 9/16" center-to-center of joint caps, it fits a variety of setups.
One of the key features of the 9533-4724 is its solid sealed U-joint design, which ensures durability and reliability under torque loads. If you’re experiencing vibrations or noise during operation, it may be a sign that your current driveshaft is worn or misaligned. Replacing it with this specific assembly can restore smooth operation and eliminate those symptoms.
- Approximate tubing length: 47.562" (weld to weld)
- Slip yoke length: 5.375" (center of joint to end of spline)
- Spline dimensions: 1.375" diameter with 16 splines
- Approximate tubing diameter: 2.000" for optimal strength
- Designed for 1310 Series universal joints with a 1.062" cap
Always ensure proper installation by verifying phasing marks and checking for runout. The 9533-4724 driveshaft is engineered to handle the torque path and load stability required in performance applications, making it a reliable choice for your next build.
Additional information
| Partn number | 9553-SF |
|---|---|
| Series | 1310 |
