6-53-151 Splined Midship Tube Shaft Splines: 1.958×10 , Fits: 3.500 X .156 Tube

The 6-53-151 Stub & Midship Shaft is engineered for optimal torque transfer and stability in driveline applications. With a spline diameter of 1.953″ and a count of 10 splines, this shaft is designed to fit specific configurations that require precise alignment and load handling. The tube diameter measures 3.500″, while the tube wall thickness is 0.156″, ensuring durability under high torque conditions.

One of the key differentiators of the 6-53-151 is its unique spline length of 2.875″ and an end-to-weld measurement of 5.156″. These dimensions are critical; using a similar shaft with incorrect spline dimensions can lead to improper fitment and potential failure during operation. The butt diameter of 3.188″ and bearing diameter of 1.968″ further enhance compatibility with various driveline components.

• Verify spline count and diameter for proper fit.
• Ensure tube diameter matches application requirements.
• Check for proper phasing during installation.
• Torque bolts to specification to prevent loosening.
• Balance the shaft if vibration occurs post-installation.

In summary, the 6-53-151 Stub & Midship Shaft is a vital component for maintaining the integrity of your driveline system. Its specific dimensions and construction make it suitable for applications that demand reliable performance and stability.
