5502-371 Flange Yoke 1550 Pilot 3.750 Bolt Circle Diameter: 4.750 Chrysler Dodge 40038047
$55.29
+50 in stock
19 People watching this product now!
Description
The 5502-371 Flange Yoke from the 1550 Series is designed for durability and precision in high-performance driveshaft applications. It features a male pilot diameter of 3.748 inches and is secured with an outside snap ring. The yoke has a robust cap width of 1.375 inches and accommodates a U-joint with a width of 4.969 inches. The bolt circle measures 4.750 inches, and the flange face to the center line is 2.248 inches. With four bolt holes and a U-joint lock up of 5.077 inches, this yoke is specifically suited for Chrysler vehicles. It is built to withstand heavy-duty conditions, providing reliable performance and strength.
Additional information
| Bolt circle dia | 4.750 |
|---|---|
| Bolt hole dia | 0.500 |
| Cj to flat | 2.250 |
| Partn number | 5502-371 |
| Pilot dia | 3.750 ,M |
| Series | 1550 |
| Bolt Holes | 4 |
