3-28-3281 Ball Stud Yoke – 1350 Series Fits Tube: 2.500 x 0.095

3-28-3281 is a Ball Stud Yoke designed for 1350 Series applications, specifically tailored to meet the demands of robust driveline systems. This yoke connects the driveshaft to the transmission or differential, ensuring reliable torque transfer while accommodating the necessary axial movement during suspension travel.

Key specifications include a Butt Diameter of 2.321 inches and a Ball Stud Length Diameter of 0.600×0.500 inches. The yoke’s design allows for precise fitment to the corresponding components, ensuring optimal performance. The tube diameter wall measures 2.500X0.095, providing the necessary strength and durability for demanding applications.

• Fits 1350 Series applications
• Ball Stud Length Dia: 0.600×0.500
• Butt Dia: 2.321 inches
• Center U J to Weld: 1.730 inches
• Notes: DUST COVER RUBBER

When installing the 3-28-3281, it’s crucial to check the spline engagement depth and ensure proper phasing with the opposite yoke. This attention to detail prevents premature wear and potential failure. The yoke’s design is particularly effective in applications where dust cover rubber is required, providing an additional layer of protection against contaminants.

In summary, the 3-28-3281 Ball Stud Yoke is engineered to deliver reliability and performance in 1350 Series configurations, making it an essential component for any driveline system.
