200-7906 Cross Bearing Kit 32×106|36×89 Combo U-joint AW36-80 Series Weasler Series 2580 Multiple Series 5200796

Shimmy at 60, clunk at takeoff, or grease dust around the caps — any one of those means the u-joint is done. The 200-7906 Cross Bearing Kit 32x106|36x89 Combo U-joint AW36-80 Series Weasler Series 2580 Multiple Series 5200796 is the correct replacement.

Zerk in the bearing cap rather than the cross — Spicer's Super Duty design. Accessible on most setups without removing the driveshaft.

Retention is Outside Snap Ring (OSR) — Clips retain cap from outside the yoke bore. Most common retention method on domestic trucks. No special tools needed — standard snap ring pliers work. Additional: Cross and Bearing Kit. 32 mm x 36 mm x 89.0 mm x 106 mm.

Spec dimensions: 1.410" cap, 1.260" cap (secondary), 3.500" width, 4.160" width (secondary). Cross-reference your original part number or measure the yoke bore before ordering.

Key Features

• Cap diameter: 1.410" cap diameter / 1.260" (secondary) — must match yoke bore exactly for correct seating
• Width: 3.500" overall width / 4.160" (secondary) — verify against yoke ear spacing
• Outside Snap Ring (OSR) retention — Standard U-joint press and snap ring pliers.
• Cap-Greasable — grease fitting in bearing cap — Spicer Super Duty lube style
• UDS brand — direct-fit replacement dimensioned to OEM spec
• Note: Cross and Bearing Kit. 32 mm x 36 mm x 89.0 mm x 106 mm

Specifications

• SKU: 200-7906
• Brand: UDS
• Cap Diameter: 1.410" / 1.260"
• Width: 3.500" / 4.160"
• Style: Outside Snap Ring (OSR)
• Greasable: Cap-Greasable
• Notes: Cross and Bearing Kit. 32 mm x 36 mm x 89.0 mm x 106 mm
