2-4-0523 – End Yoke – 1310 Series – 2.125″ Hub Dia – 2.562″ Cj To End

When you’re working with the 2-4-0523 End Yoke, it’s crucial to understand how it connects the driveshaft to the transmission, transfer case, or differential. This yoke is built for 1310 Series applications, featuring a 2.125″ hub diameter and a 2.562″ Cj to end length. The round bore splines with a diameter of KEYWAY- 0.312 ensure a secure fit, but you need to verify the spline engagement depth before installation.

Common mistakes during installation often stem from overlooking the keyway location, which is at 12 o’clock for this yoke. Always check that the yoke aligns properly with the mating component to avoid misalignment issues that can lead to premature wear or failure. Remember, never force the spline entry; if it doesn’t slide in smoothly, double-check your alignment and spline count.

• Check spline count and diameter before installation.
• Ensure the keyway aligns at the 12 o’clock position.
• Verify phasing with the opposite yoke for optimal performance.
• Inspect the mating components for wear and damage.
• Use appropriate torque specifications for bolting to companion flanges.

With the 2-4-0523, you’re equipped to handle the demands of your driveline setup. Its robust construction and precise dimensions make it a reliable choice for any technician looking to maintain or upgrade their vehicle’s performance.
