170-4-811-1 – End Yoke – SPL170 Series – 2.024″ Splines Dia – 3.000″ Hub Dia
$416.25
1 in stock
19 People watching this product now!
Description
The 170-4-811-1 End Yoke connects driveshafts with a 3.000″ hub diameter and 39 splines for SPL170 Series applications.
Full Description
170-4-811-1 is an End Yoke designed to connect the driveshaft to the transmission, transfer case, or differential. This component features a 3.000" hub diameter and 39 splines with a diameter of 2.024". If you're experiencing vibrations or unusual noises during operation, a worn or damaged yoke could be the culprit. Symptoms like these often indicate that the splines are not engaging properly, leading to misalignment or excessive wear.
When diagnosing driveline issues, always check the spline engagement depth and ensure that the yoke is properly phased with the opposite yoke. A mismatch in spline count or diameter can lead to assembly failures. The 170-4-811-1 End Yoke is built for SPL170 Series applications, making it crucial to verify compatibility before installation.
- Hub Diameter: 3.000"
- Spline Count: 39
- Spline Diameter: 2.024"
- Cj to End Length: 6.250"
- Through Hole: 2.250"
Using the correct yoke is essential for maintaining driveline integrity. If you notice any signs of wear or if the yoke is not functioning as expected, replacing it with the 170-4-811-1 will restore proper operation and prevent further damage to your driveline components.
Additional information
| Cj to end | 6.250" |
|---|---|
| Hub dia | 3.000" |
| Partn number | 170-4-811-1 |
| Series | SPL170 |
| Splines count | 39 |
| Splines dia | 2.024 |
| Style | BS |
| Through hole | 2.250" |
