Companion Flanges
More categories:
Filters Sort results
Reset Apply
Image | Add | Part Number | Splines count | Splines dia / Bore Dia | Hub Dia | Through hole | Pilot dia | Bolt Holes | Face To End | Keyway | Bolt Circle Dia | Outside Dia | Notes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 23 | 0.990" | 1.500" | 1.530 | 1.808 | 2.234 | 3.340 | Toyota Mid-ship, SQ | |||||
 | 28 | 1.218 | 1.812 | 1.252 | 2.000 | 3.50/4.250 | Dual bolt pattern | ||||||
 | 32 | 1.401 | 1.943 | 2.000 | 2.000 | 4.250 | Front 07-17 JEEP JK T-case Adapter, can use 3594-2000U, M12-1.75mm , 4 holes drilled for M12 | ||||||
 | 32 | 1.401 | 1.943 | 2.000 | 2.000 | 4.250 | Rear 2007-2017 JEEP JK T-case Adapter, can use 3594-2000U, M12-1.75mm, 4 holes drilled for M12 | ||||||
 | 26 | 1.146 | 1.400 | 1.535 | 3.937 | 3.386 | Uses 2352-1001 (plunge) | ||||||
 | 23 | 990 | 1.495 | 1.540 | 3.937 | 3.386 | Uses 2352-1001 (plunge) | ||||||
 | 26 | 1.146 | 1.554 | 1.535 | 3.937 | 3.386 | Uses 2352-1001 (plunge) | ||||||
 | 1.250 | 1.925 | 2.375 | 0.312 | 3.125 | 3.875 | 1310 ser | ||||||
 | 32 | 1.401 | 2.125 | 2.000 | 2.000 | 3.5, 4.25 | Counterbore depth .421", USE WITH: 3594-2000U or equv. Ford NP205 NP203, M12-1.75mm | ||||||
 | 10 | 1.500 | 1.772 | 2.000 | 2.245 | 4.000 | Sprinter, threaded bolt holes, male pilot | ||||||
 | 30 | 1.312 | 1.812 | 1.250 | 2.000 | 3.50 / 4.25 | Ford 8.8, Dual threaded bolt patterns | ||||||
 | 31 | 1.343 | 1.812 | 1.640 | 2.000 | 3.50 / 4.25 | Dual threaded bolt patterns, M12-1.75mm, Superduty transfer case, typically 3594-2000U | ||||||
 | 29 | 1.263 | 1.875 | 1.500 | 2.161 | 3.937 | Chy 9.25, threaded bolt holes | ||||||
 | 31 | 1.387 | 2.205 | 1.469 | 2.953 | 4.750 | Ford Transit Flex coupler to flange conversion (3502-1859, 4102-1839) | ||||||
 | 29 | 1.276 | 1.875 | 1.500 | 2.000 | 4.250 | Dana 60, 70 Pinion Conversion Flange | ||||||
 | 32 | 1.401 | 1.943 | 2.000 | 2.000 | 4.250 | Rear 2007-2017 JEEP JK T-case Adapter | ||||||
 | 10 | 1.750" | 2.148 | 2.728 | 3.150 | 4.343 | Isuzu / Mates with 4802-1244 | ||||||
 | 32 | 1.401 | 1.943 | 2.000 | 2.000 | 4.250 | Front 2007-2017 JEEP JK T-case Adapter | ||||||
 | 32 | 1.401 | 2.125 | 2.000 | 1.808 | Blank | 5.475 OD | ||||||
 | 30 | 1.250 | 1.848 | 1.000 | 0 | 100mm | Pinion Tri-Flange V6 12/18 Bolt hole | ||||||
 | 31 | 1.380 | 1.890 | 2.000 | 2.000 | 4.25 | SQ Pattern, Counter Bore .25 , Borg Warner TC 1356 | ||||||
 | 2.820 | 5.000 | 4.250 | Caravan adapter for 3194-100 CVJ |
