Inside Snap Ring Style End Yoke

Measure an inside snap ring end yoke: width between the yoke ear flats and the cap opening, with common u-joint sizes by series.

Inside snap ring u-joint: width and cap diameter
Inside snap ring end yoke: where to measure

Width: measure from the inside flat of one yoke ear to the inside flat of the other ear

Cap Diameter: measure the width of the opening where the cap sits in the yoke

Common Inside Snap Ring U-joint Sizes and Series

SeriesWidthCap Diameter
7260 CHRYSLER 2 1/8″ = 2.125 1 5/64″ = 1.078
7290 CHRYSLER 2 5/8″ = 2.625 1 1/8″ = 1.125
3R GM 2 9/16″ = 2.563 1 1/8″ = 1.125
