2252-681 – Weld Yokes – CVJ Series – Butt Dia 2.375″ – Tube Dia Wall 2.500X0.065

When you’re ready to install the 2252-681 weld yoke, ensure you have a solid understanding of its specifications and application. This yoke is specifically designed for IRS suspension systems, making it a critical component for maintaining proper driveline geometry. The 2252-681 features a butt diameter of 2.375 inches and a tube wall thickness of 0.065 inches, providing a robust yet flexible connection.

Before installation, double-check the center U-joint to weld distance of 3.500 inches to ensure a precise fit. It’s essential to verify that the yoke aligns correctly with the opposite yoke to maintain proper phasing. A common mistake is assuming that all yokes fit the same; always confirm the CVJ series designation for compatibility.

• Check the spline engagement depth before sliding the yoke onto the shaft.
• Ensure the tube diameter of 2.500 inches matches your existing setup.
• Inspect the material; this yoke is made from durable steel, ideal for IRS applications.
• Pay attention to the installation angle; this yoke operates at a 0.000 angle.

Using the right tools, such as a torque wrench, can help you secure the yoke to the companion flange effectively. Remember, the 2252-681 is not just a part; it’s a vital link in your driveline that ensures smooth operation and longevity. Trust in UDS for quality and performance in your builds.
